Progressive Die

Description: Snow Shoe Ice Crampon
Material: .060" Stainless Steel
Overall Size of Part: 6" Long x 4.5" Wide x 1.5" High
Finish: Plain Stainless Steel
Processes to Manufacture: Progressive Die



Progressive Die

Description: Snow Shoe Ice Crampon
Material: .125" 5052-H-32 Aluminum
Overall Size of Part: 5" Long x 4" Wide x 1.5" High
Finish: Plain Aluminum
Processes to Manufacture: Progressive Die



Progressive Die

Description: Drawn Threaded Cup
Material: .035" G60 Galvanized Steel
Overall Size of Part: 2.375" Dia x 1.370" Deep
Finish: Galvanized
Processes to Manufacture: Progressive Die



Sprinkiler Support Cup

Description: Sprinkler Support Cup
Material: .020" 1005-1020 Steel
Overall Size of Part: 2.275" Dia x 1.510" Deep
Finish: Yellow Chromate Conversion Plate
Processes to Manufacture: Progressive Die



Sleeve for Door Lockset

Description: Sleeve for Door Lockset
Material: .057" Aluminum Killed 1008 Steel
Overall Size of Part: 1.080" Dia x .900" High
Finish: Zinc Chromate Plate
Processes to Manufacture: Progressive Die



Tube for Door Lockset

Description: Tube for Door Lockset
Material: .070" #4 Temper Steel
Overall Size of Part: .786" Dia x 2.50" Long
Finish: Zinc Chromate Plate
Processes to Manufacture: Progressive Die



Sprinkler Component

Description: Sprinkler Component
Material: .072" 1/2 Hard Phosphor Bronze
Overall Size of Part: 1.25" Long x .877" High
Finish: Chrome over Nickel Plate
Processes to Manufacture: Progressive Die



Sprinkler Shell

Description: Sprinkler Shell
Material: .030: 260 Brass
Overall Size of Part: 3.187" Dia x .750" Deep
Finish: Plain Brass
Processes to Manufacture: Progressive Die



Drop Wire Hook

Description: Drop Wire Hook
Material: .225" Dia Steel Wire
Overall Size of Part: 1.625" Wide x 1.435" High
Finish: Plain Steel
Processes to Manufacture: Fourslide



Wireform

Description: Wireform
Material: .093" #1008 Steel
Overall Size of Part: 1.187" Long with .125" Eye
Finish: None
Processes to Manufacture: Fourslide

Progression for Sprinkler Trim

Description: Progression for Sprinkler Trim
Material: .020 #1008 Steel
Overall Size of Part: 2.875" Wide x 10 Progressions
Finish: None
Processes to Manufacture: Progressive Die



 Progression for Electrical Component

Description: Progression for Electrical Component
Material: .100" Thick Stainless Steel
Overall Size of Part: 1.875" Wide x 13 Progressions
Finish: None
Processes to Manufacture: Progressive Die

Handle; Screw Eye; Screw Hook

Description: Handle; Screw Eye; Screw Hook
Material: .312" Dia; .306" Dia; .270" Dia
Overall Size of Part: 4.625" x 3"; 2.875" x 7/8" Dia Eye; 4.375" x 1" Dia Hook
Finish: Plain Steel
Processes to Manufacture: Fourslide



Thimble

Description: Thimble
Material: Stainless .030 thru .080"
Overall Size of Part: .350" Dia Eye thru 1.00" Eye
Finish: Stainless or Plated Steel
Processes to Manufacture: Fourslide
